Cordoba Fusion 5 Classical - Sonata Burst
CORDOBA-5-SNBCórdoba’s entry into the fusion line! The perfect choice to transition from a steel string to a nylon guitar, the Córdoba Fusion 5 features a solid spruce top, mahogany back and sides, a full body with cutaway for extended playing range, side dot fret position markers, and a pearl decal rosette and arches. The fusion neck with a 16” radius fretboard and smaller, 1 7/8” (48mm) nut width provides a playing experience very close to that of a steel string guitar. This familiarity offers an easy transition for steel string players and players with smaller hands to the world of nylon string guitar. Added side dot markers also depart from traditional nylon string guitar construction, providing players reference for their position on the fretboard. Equipped with the Fishman Presys VT Pickup System, the Fusion 5 is ready to plug in and play. Available in Gloss Natural and Jet-Black finish with mahogany back and sides and Gloss Sonata Burst with elegant flamed mahogany back and sides.
Back Purfling Inlay Pattern & Dimensions | N / A |
---|---|
Build | Fusion |
Soundboard Thickness | 2.8 - 3.0 mm |
Construction | Solid Top |
Body Top | Solid Spruce |
Exclusive | No |
Family | Cutaway & Electric |
Does it contain shell? | No |
Shipper Carton Dimensions | 104 x 47 x 14 (cm) - Cordoba Guitar Triangle Box (No Case) |
Top Bracing Pattern | Fan |
Soundhole Diameter | 84mm (3.3") |
Rosette | Pearl Style Decal |
Top Binding | Composite |
Back Bracing | Ladder Bracing |
Back Binding | Composite |
Side Purfling Inlay Pattern & Dimensions | N / A |
Back Center Strip | Composite |
Side Purfling Inlay | N / A |
Back and Sides Wood | Flamed Mahogany |
Back Purfling Inlay | N / A |
Top Purfling Pattern & Dimensions | N / A |
Frets to Body | 12 |
Neck Material | Mahogany |
Scale Length | 650mm (25.6") |
Compatible Case 1 | ACHUMPR-04072 - HumiCase Protégé Classical |
Neck Construction | Traditional 3 Piece Neck |
Neck Joint | Dovetail |
Neck Shape | C Shape |
Nut Width | 48mm (1 7/8") |
Neck Thickness 1st Fret | 21mm |
Neck Thickness 9th Fret | 24mm |
Battery Pack | Battery Pouch - 9V |
Truss Rod | Dual Action |
Headstock Logo | Cordoba Arches Logo - Pearl Style Decal |
Replacement Saddle | 01066 - Cordoba Saddle Bone 6 String Guitar Radiused 80mm x 3mm |
Truss Rod Wrench | 4mm Allen Key |
Fret Dimensions | 2.0mm (W) x 1.1mm (H) |
Replacement Gig Bag | N / A |
Fingerboard Material | Pau Ferro |
Headplate | Pau Ferro |
Fingerboard Inlays | N / A |
pcid | 1 |
Frets Total | 19 |
Compatible Gig Bag 1 | ACCASIB-03543 - Cordoba Deluxe Gig Bag Classical Full Size |
Color | Sonata Burst (SNB) |
Finish | Gloss Polyurethane |
Bridge Material | Pau Ferro |
Tap Plate | N / A |
Replacement Pickup & Preamp System | ACFISHM-05065 - Cordoba Pickup Fishman Presys VT Complete |
Replacement Output Jack | N / A |
Pickup Type | Undersaddle Piezo |
Middle Pickup | N / A |
Compatible Case 2 | 03754 - Cordoba Humidified Archtop Wood Case CL/FL Full Size Brown |
Electronics Vendor & Model | Fishman OEM-SON-CL4 |
Tuning Machine Buttons | Black |
Tuning Machine Ratio | 14:1 |
Tuning Machines Vendor & Model | Der Jung DJ206CK-P12 (S3) |
Tuning Machines | Cordoba Silver with Black Buttons |
Electronics | Fishman Presys VT Classical |
Controls | Master Volume and Tone |
Strings | Savarez Cristal Corum High Tension 500CJ |
Replacement Tuning Machine - Treble | ACCORTM-05682 - Cordoba Tuner Honeycomb NKL w/EB OV BTN Treble |
Upper Bout Width | 292mm (11 1/2") |
Replacement Bridge Pins | N / A |
Replacement Nut | 01053 - Cordoba Nut Bone 6 String Guitar 48mm x 5mm |
Replacement Pickguard | N / A |
Replacement Truss Rod Cover | N / A |
Replacement Truss Rod Wrench | 008-0000-001 - Truss Rod Wrench 4mm Allen Key |
Replacement Tuning Machine - Bass | ACCORTM-05683 - Cordoba Tuner Honeycomb NKL w/EB OV BTN Bass |
Replacement Tuning Machine Button | N / A |
Tuning | E-A-D-G-B-E |
Waist Width | 248mm (9 3/4") |
Number of Strings | 6 |
Lower Bout Width | 371mm (14 5/8") |
Target Instrument Weight | 3 lbs / 1.4 kg |
Body Depth Upper Bout | 95mm (3 3/4") |
Body Depth Lower Bout | 100mm (4") |
Body Length | 489mm (19 1/4") |
Replacement Battery Box & Output Jack | 05013 - Cordoba Pickup Part Fishman Battery Box Output Jack Unit |
Battery Pack Installation Location | Lower Bout Treble Side |
Replacement Case | N / A |
Nut Material | Bone |
Overall Length | 984mm (38 3/4") |
Country of Origin | China |
Compatible Case 3 | ACCORGB-03780 - Cordoba Polyfoam Case Classical Full Size |
Saddle Material | Bone |
Compatible Gig Bag 2 | ACCORGB-03750 - Cordoba Standard Gig Bag Full Size |
