Cordoba

Cordoba Fusion 5 Limited Edition Classical - Bocote

CORDOBA-5-LTD
Regular price $899.00
Regular price $0.00 Sale price $899.00
% OFF Sold out
Tax included.

Córdoba’s new, entry-level fusion line in stunning Bocote wood! The perfect choice to transition from a steel string to a nylon guitar, the Córdoba Fusion 5 Limited features exotic Bocote back and sides, a full body with cutaway for extended range, side dot fret position markers, and a pearl decal rosette and arches. The fusion neck with a 16” radius fretboard and smaller, 1 7/8” (48mm) nut width provides a playing experience very close to that of a steel string guitar. This familiarity offers an easy transition for steel string players and players with smaller hands to the world of nylon string guitar. Added side dot markers also depart from traditional nylon string guitar construction, providing players reference points for hand position on the fretboard. Available with a solid spruce top, fusion neck with a 16” radius fretboard and 48mm nut. Equipped with the Fishman Sonitone Pickup System, the Fusion 5 Limited is ready to plug in and play. Available in Natural Gloss Finish.

psid 4
Replacement Tuning Machine Button N / A
Tuning Machines Vendor & Model Der Jung DJ216GK-A1W (S2)
Tuning Machine Ratio 14:1
Tuning Machine Buttons Pearl White
Electronics Vendor & Model Fishman OEM-SON-CL4
Pickup Type Undersaddle Piezo, Onboard Tuner
Middle Pickup None
Battery Pack Fishman Combination Battery Box/Output Jack - 9V
Battery Pack Installation Location Lower Bout Treble Side
Waist Width 248mm (9 3/4")
Target Instrument Weight 3 lbs / 1.4 kg
Number of Strings 6
Tuning E-A-D-G-B-E
Replacement Tuning Machine - Treble ACCORTM-05682 - Cordoba Tuner Honeycomb NKL w/EB OV BTN Treble
Replacement Tuning Machine - Bass ACCORTM-05683 - Cordoba Tuner Honeycomb NKL w/EB OV BTN Bass
Replacement Truss Rod Cover N / A
Headstock Logo Cordoba Arches Logo - Pearl Style Decal
Replacement Truss Rod Wrench 008-0000-001 - Truss Rod Wrench 4mm Allen Key
Replacement Nut 01053 - Cordoba Nut Bone 6 String Guitar 48mm x 5mm
Replacement Pickguard N / A
Replacement Bridge Pins N / A
Replacement Saddle 01066 - Cordoba Saddle Bone 6 String Guitar Radiused 80mm x 3mm
Replacement Pickup & Preamp System ACFISHM-05065 - Cordoba Pickup Fishman Sonitone Complete
Replacement Battery Box & Output Jack 05013 - Cordoba Pickup Part Fishman Battery Box Output Jack Unit
Replacement Output Jack N / A
Replacement Case N / A
Replacement Gig Bag N / A
Compatible Case 1 ACHUMPR-04072 - HumiCase Protégé Classical
Compatible Case 2 03754 - Cordoba Humidified Archtop Wood Case CL/FL Full Size Brown
Compatible Case 3 ACCORGB-03780 - Cordoba Polyfoam Case Classical Full Size
Compatible Gig Bag 1 ACCASIB-03543 - Cordoba Deluxe Gig Bag Classical Full Size
pcid 1
Compatible Gig Bag 2 ACCORGB-03750 - Cordoba Standard Gig Bag Full Size
Headplate Composite
Exclusive to AIMM
Top Purfling Pattern & Dimensions N / A
Side Purfling Inlay Pattern & Dimensions N / A
Back Center Strip Composite
Back Bracing Ladder Bracing
Back Binding Composite
Soundboard Thickness 2.8 - 3.0 mm
Back Purfling Inlay Pattern & Dimensions N / A
Neck Construction Traditional 3 Piece Neck
Frets to Body 12
Neck Joint Dovetail
Shipper Carton Dimensions 104 x 47 x 14
Does it contain shell? No
Family Cutaway & Electric
Build Fusion
Construction Solid Top
Body Top Solid Spruce
Top Bracing Pattern Fan
Soundhole Diameter 84mm (3 1/3")
Rosette Pearl Style Decal
Top Binding Composite
Side Purfling Inlay N / A
Back and Sides Wood Bocote
Back Purfling Inlay N / A
Neck Material Mahogany
Scale Length 650mm (25.6")
Neck Shape C Shape
Nut Width 48mm (1 7/8")
Neck Thickness 1st Fret 21mm
Neck Thickness 9th Fret 24mm
Truss Rod Dual Action
Truss Rod Wrench 4mm Allen Key
Fingerboard Material Pau Ferro
Fingerboard Inlays N / A
Frets Total 19
Color Natural (NAT)
Finish Gloss Polyurethane
Bridge Material Pau Ferro
Saddle Material Bone
Nut Material Bone
Tuning Machines Cordoba Silver with Black Buttons
Tap Plate N / A
Electronics Fishman Sonitone Classical
Strings Savarez Cristal Corum High Tension 500CJ
Upper Bout Width 292mm (11 1/2")
Lower Bout Width 371mm (14 5/8")
Body Depth Upper Bout 95mm (3 3/4")
Body Depth Lower Bout 100mm (4")
Body Length 489mm (19 1/4")
Overall Length 984mm (38 3/4")
Country of Origin China
